MINIMAL SYSTEMs
A window that seems to float, gliding open with effortless ease.
38M Minimal series
Our foundational sliding High-end Minimal system, the 38mm Series, is engineered for durability, smooth operation, and cost-effective performance across residential projects. Built to support larger glass panels without compromising wind load resistance or thermal efficiency, it combines structural strength with proven aluminum craftsmanship — a trusted choice for homeowners and demanding project specifications alike, without compromise. With different options for the bottom track, it creates a seamless, zero-threshold transition between interior living spaces and outdoor patios.
FEATURES
- Less Aluminium
- 5 Tracks of Options
- Maximum Views
Technical Characterstics
- Max Shutter Height - 5500mm
- Max Shutter Width - 1800mm
- Glass - 12mm SGU 17.52mm / 22.28mm Laminated 34mm / 38mm DGU
- Interlock Visible Width - 20mm
- Meeting Stile Visible Width - 64mm
- Shutter Weight Capacity - 200kg / 310kg / 425kg / 550kg
- Track Joinery - 45°
- Shutter Joinery - 90°
- Lock Mechanism - Multipoint






BENEFITS
- A Wall of Glass, Not a Window
- Seamless Indoor–Outdoor Transition
- Smooth Operation Under Heavy Load
